T Max L Light Solar aesthetic solar metal tile
Stone coated roof tile accessories for solar tile is made of stone coated roof tile ,acrylic resin layer,Aluminum zinc roof sheet- protects the steel plate and improves corrosion resistance. The stone coated roof tile is used as shingle PV accessories roof cover for the area of the roof top which are not covered with solar tile , it is well match the frame basement of shingle PV.
- Information
- Video
- Download
Embedded module design, stone coated metal bottom support, creating a lightweight roof that can generate electricity.
PHYSICAL PARAMETERS | |
Color | Black |
Dimensions | 1340*420mm |
Weight | 6.8kg |
Glass (material/thickness) | Tempered glass/3.2mm+Backplane |
Cell | 182*91mm（3*6） |
Junction box | ≥IP67 |
Cable type | 500mm / 4mm² |
Plug connector | MC4 |
Life span | >30years |
ELECTRICAL PARAMETERS(STC) | |
Solar cells | Monocrystalline |
Power output（Pmax ） | 80W |
Module efficiency（%） | 19.40% |
Voltage at Pmax（V mpp） | 14.7V |
Current at Pmax（I mpp） | 5.44A |
Open-circuit current（Voc） | 17.7V |
Short-circuit current（Isc） | 5.71A |
Performance Grade
Selling Point
Maximum flexibility：Modular system fits many type of roofs
Lightweight: 12kgs per square meter, reduce the load on the building structure
Aethetic looking: the solar roof tiles blend seamlessly into your roof and are almost indistinguishable from regular roof tiles.
Details
Wood grain structure, Stable lap and self-draining
Embedded design, High-efficiency and integrated
Accessories Tile
Stone Chips:Beautiful look, effective heat/UV resistant, noise reduction, anti-slip and etc features
Galvalume Steel Plate: Eco-friendly and recyable material, strong, light-weight, anti-corrosion, waterproof
Acrylic Glue: Premium sealing performance, strong adhesion, anti-algae
Product Name | T Max L stone coated accessories roof tile |
Raw Materials | *Alu-Zinc PPGL Galvalume Steel Plate, sintered Stone Chips ( 20 years no color fading), acrylic Glue |
Color Options | 15 popular color options (single/mixing colors); more vibrant beautiful colors can be customized |
Certifications | CE,ISO9001, COC, CO and etc. |
Effective Size | 1340mm*420mm/1400mm*420mm |
Coverage Area | 1290mm*370mm/1350mm*370mm |
Thickness | 0.3mm-0.55mm |
The Number Of Pavement | 2.08 - 2.16pcs/sqm |
Packing | 450-650 pcs/pallet |
Main features | Easy to install; Lightweight; Economic; Eco-friendly; Anti Corrosion; Extreme weather conditions resistant; noise reduction; |
Engineering Rendering
Case
Tanzania
Hangzhou, China
