Curved solar energy roof tiles bipv Low Carbon Buildings
Curved surface solar energy roof tiles are mainly used in antique building renovation, roof remodeling, high-end villas, etc. They are waterproof and heat insulation, hail and lightning resistant.
- gainsolar
- hangzhou
- Information
T MAX S combines both architectural style and aesthetics. Its beautiful curved shape attracts many people and is a great breakthrough in PV building integration. It has a beautiful shape and can also generate electricity. Through roof light, it generates heat energy to generate electricity, which is practical and popular among the general public. Curved surface solar energy roof tiles are currently available in only three colors, black red gray, other colors can be customized according to customer demand.
T MAX S uses monocrystalline silicon cells inside and makes a curved shape, which is the only company in the world with this process and equipment, and a great breakthrough in the PV industry. The advantages of the T MAX S are therefore obvious, with its beautiful shape and amazing power generation, which can reach an output of up to 35w per cell and a staggering 140w per square meter.
Product details
The beautiful curves of solar energy roof tiles are enough to draw all eyes to them, and the T MAX S has that charm.
| PHYSICAL PARAMETERS | |
| Product model | JS30DG-6b1/2 |
| Color | Black |
| Dimensions | 580*400mm |
| Weight | 5kg |
| Glass (material/thickness) | Tempered glass/3.2mm+Backplane |
| Solar Cell Type | 182*91mm（2*5） |
| Junction box | ≥IP67 |
| Cable type | 300mm / 4mm² |
| Plug connector | MC4 |
| Life span | >30years |
| ELECTRICAL PARAMETERS(STC) | |
| Solar cells | Monocrystalline |
| Power output（ Pmax ） | 30W |
| Module efficiency（%） | 15.00% |
| Voltage at Pmax（Vmpp | 5.7V |
| Current at Pmax（Impp） | 5.14A |
| Open-circuit current（Voc） | 6.74V |
| Short-circuit current（Isc） | 6.53A |
Installation details
The solar energy roof tiles are easy to install, just like traditional tiles, but with the additional step of connecting the cables. sgbsolar's special engineers design the tiles before the project begins to ensure that the construction is accurate.
The effect
Solar energy roof tiles can be perfectly matched to the antique building, and seem to blend in with the building as a whole without being obtrusive, which is the biggest advantage of BIPV.
How to install？
