T Max O Flat Solar cell electric Clay PV tile

T max tile O series solar tile is made of ploymer resin tile and

photovoltaic modules.It can be integrated with the roof.Easy to installation

  • Information
  • Download


T-max Tile-O replace standard roofing tiles or solar panels, which can give you a weatherproof roof covering and electricity generating solution.They enhance design possibilities, creating sleek aesthetics.


Double 3.2mm Tempered Glass can protect solar module very well, polymer resin bottom tiles are durable and strong. with 10 year limited product warranty, 25 year limited power warranty at 80%.

T-max Tile-O will continue to produce clean energy.


solar cell tiles



PHYSICAL PARAMETERS

Product model

JS90DG-13e 1/2

Dimensions

1260*480mm

Weight

15.5kg

Glass (material/thickness)

Tempered glass/3.2mm+Backplane

Cell

182*91mm(2*12)

Junction box

≥IP67

Cable type

900mm / 4mm²

Plug connector

MC4

Life span

>30years

ELECTRICAL PARAMETERS(STC)

Solar cells

Monocrystalline

Power output(Pmax )

90W

Module efficiency(%)

18.90%

Voltage at Pmax(V mpp)

13.7V

Current at Pmax(I mpp)

6.57A

Open-circuit current(Voc)

16.3V

Short-circuit current(Isc)

6.89A


Selling Point

Suitable for all bad weather


solar cell roof shingles


Load grade 2400pa, allow people to stand on it


solar cell roof tiles


Three colors for choice

solar cell tiles

Details Selling Point

Easy Installation:

Installation workers and electricians can quickly complete the

installation work under the guidance of the installation manual


solar cell roof shinglessolar cell roof tiles


Durability:

Double 3.2mm Tempered Glass protect solar module very well

solar cell tiles

Accessories Tile

1. Raw materials: Premium weather resistance polymer resin composite material

2. Roof tile lifespan: more than 70 years

3. Relevant physical properties: the high temperature resistance is above 300 degrees, and the frost resistance is about minus 70 degrees. The product reaches the b1 level fire protection standard.

4. Product weight per square meter: The weight per square meter is about 20 kilograms, which is one third of the weight per square meter of sintered clay tiles.

5. Product surface coating: environmentally friendly high weather-resistant polyester fluorocarbon paint, to ensure 30 years of non-fading.


Product Name

Polymer Resin Synthetic Roof Tiles for Solar Roof accessory tile

Raw Materials

Fiberglass, Polymer Resin, Clay (Synthetic)


A variety of polymer composite materials and high-strength basalt fiber

Lifespan

70+ Years (Living same lifespan with the building)

Features (Physical Properties)

Extreme temperature resistance ( -70 to 300); High strength;


B1 level of fire-resistance standard; Anti-UV ; Algae resistant

Weight

20 kgs/Sqaure Meter (Only 1/3 weight of traditional clay roof tiles)

Qty/Sqm

About 4 pcs of main roof tiles to cover 1 square meter exposure area

Color

Black / Red /Grey / Customizable

Surface Coating

Environmentally friendly high weather-resistant polyester fluorocarbon paint ensures 30 years no color fading.

Main Roof Tile Size

630x480x5mm


solar cell roof shingles

solar cell roof tiles

solar cell tiles

solar cell roof shingles


Projects

Huizhou

solar cell roof tiles



Ningguo


solar cell tiles


Tibet


solar cell roof shingles
